Pinnacle Modbus Luminaire Controller

LUMINAIRE PORTS (PCB CHANNELS 1–8) Port 1 Active

Port 1: Matrix Dyna M8

● Flexstar V1.1 Modbus RTU • Slave ID: 0x64

4-CH SPECTRUM

Main White Output

100%

Fixture Rating

680W Max

100%

80%

40%

20%

Horticultural Spectral Presets

🌱 Veg Boost 100/25/0/10

🌸 Flower Bulk 100/100/40/25

⚡ Emerson EOD 15/20/100/0

🍇 Trichome Finish 80/60/15/100

☀️ 100% Full 100/100/100/100

🌑 All Off 0/0/0/0

Autonomous Schedule Engine

Independent Port & Channel Photoperiods • Burst Timing Engine

ACTIVE

SELECT LUMINAIRE PORT (1–8)

Port 1: Matrix Dyna M8

Configure independent channel photoperiods & burst timing

STANDALONE

Channel 1 • Main White

3000K + 5000K Daylight Spectrum

24-HOUR AUTONOMOUS TIMELINE 16h ON / 8h OFF

00:00 04:00 08:00 12:00 16:00 20:00 24:00

Photoperiod Presets

🌅 Lights ON Time

🌙 Lights OFF Time

Target Photoperiod Intensity 100%

Sunrise & Sunset Soft Ramp 30 min

Gradual linear ramp at sunrise and sunset prevents plant photo-inhibition.

⚡ 100% Offline Edge Autonomy

All port and channel photoperiods and burst schedules run autonomously on the controller's onboard RTC clock. The phone does not need to remain connected.
